FT08-H0440C Toyota 8A Emulator 사용 방법 설명
원본 자동차의 키가 잃어 버린 (분실) 상태에서 다시 이 제품으로 비상용 키를 생성하는데 사용됩니다.
서버로 분실 된 키 데이터를 계산하여 분실 된 키로 생성되기 때문에 원격 제어 충돌이 발생하지 않습니다.
현재는 신형의 AVALON、ES 및 GS와 같은 8A 키를 지지하며 신형 LEVIN 및COROLLA를 지지하지 않습니다.
직접 등록하기에는 원본 자동차 키 데이터 P4 페이지 [91 00 AA AA] 만 지지합니다.
FT08-H0440C의 용도:
1. 비상 시동용 키로 생성하기: 예를 들어, OBD로 등록을 수행 할 수 있지만 EEPROM 데이터를 백업 할 수없는 일부 모델 (페이지 P4 [91 00 A9 A9]), H0440C를 사용하여 데이터를 수집하고 비상 키를 생성하여 자동차 계기판을 켜고, 그런 다음 자동차 해당 키를 추가등록하십시오. 비상시 작동하기 위해 생성된 키는 일상에서 사용하는 키와 다릅니다. 지능적이지 않으며 시뮬레이션 된 키의 특성과 동일합니다.
2. 분실된 스마트키로 생성하기: 신형차량이며 P4페이지 [91 00 A9 A9] [91 00 AA AA] 인 경우, H0440C를 사용하여 데이터를 수집하여 원본 스마트 키처럼 자동차를 시동할 수 있습니다.
사용시 따로 필요되는 것은:
1. K518기기혹은 KH100기기를 갖고 있음
2. 작업시 인터넷에 연결되어 있어야함
3. 1 년간 서비스 요금을 지불하기>>>1 년간 서비스 요금에 대한 자세한 내용은 본사 한국 업무 담당과 확인하십시오. 메일 주소: tomato@lockpick.cn
[1 년간 서비스 요금]타이밍 규칙 : 최초 사용 시점부터 시작됩니다.구입한 후 6 개월 이내에 사용하지 않은 경우 타이밍 자동으로 시작됩니다.
참고 : AVALON、ES와 같은 신형의 Toyota 및 Lexus 모델 (원래 자동차 키 P4[91 00 AA AA] 만 지원)의 경우, 다시 새로운 키를 추가하려면 딜러 혹은 4S 상점으로 이동해서 필요하는 코드를 받고 나서 순정 장비를 사용하여 등록 작업하십시오.
Instructions for FT08-H0440C Toyota 8A Generation Card
(Emulator for All Key Lost)
Used for original car All Key Lost, required server to calculate the lost key data. Because is to generate the lost keys, there will be no conflict in remote control system.
Currently supports 8A keys of Asia Dragon, ES and GS , ect.. Not support Levin, Corolla, which is of the new platform yet.
Programing directly, only supports the original car key data of P4 page [91 00 AA AA].
FT08-H0440C Functions:
1. Generate emergency start.
For example, when some models that can perform OBD programming BUT cannot backup EEPROM data (page P4 [91 00 A9 A9]), you can use H0440C to collect data, generate emergency key to light up the car instrument, and then add the car key.
Generating an emergency start do not include a smart system, it cannot be totally used as a key, which is equivalent to be the feature of a simulated key (Emulator).
2. Generate a lost smart key.
For models on the new platform of page [91 00 A9 A9][91 00 AA AA], you can use H0440C to collect data and generate the original smart key, use as a car key.
*Both K518 and KH100 support this function, requires to be connected to the Internet(Online), requires to top up the service fee, valid for one year.
Additional charge for top-up, calculation period is one year (Annual Fees).
Annual fee timing rules:
Start timing from the first use; if it has not been used within six months, it will be mandatory to start timing.
Note: For Toyota and Lexus models of the latest platform (which is only support the original car key P4 page 91 00 AA AA), such as Asia Dragon, ES, if you want to add a new key, you need to go to the service station or 4S shop to calculate the code, with the original factory Equipment programming to achieve.
|
